| Series | PiranhaMAX |
| Display Size - Diagonal | 4.3" |
| Display Pixel Matrix | 272H x 480V |
| Sonar-Standard | Dual Beam |
| Sonar-Coverage | 28° & 16° @ -10dB |
| Sonar-Frequencies Supported | 200/455kHz |
| Depth-Sonar | 320 ft (20) 455 kHz, 600 ft (20) 200 kHz |
| Depth-Down Imaging | 320 ft |
| Interface | Keypad Control |
| Memory Card Slot | None |
